MB400 Cabin elevator

  • Low Installation Costs;
  • Simple Replacement of Old Elevators;
  • One-Touch Control.

If you are looking for a safe, reliable, and cost-effective solution, the MB400 cabin lift is a practical choice for a wide range of applications.

In Development
MB400

MB400 advanced Safety and practical design

The MB400 cabin elevator is an excellent choice for those looking for a safe, reliable, and affordable lift solution. Designed for both residential and commercial use, it combines modern technology with practical functionality.

In addition to its cost-effectiveness, the MB400 cabin elevator is built with advanced safety features to ensure smooth and secure operation. It is also highly energy efficient, making it a sustainable and environmentally responsible choice.

If you are looking to upgrade your existing lift system or install a new one, the MB400 elevator is a dependable solution worth considering.

MB400 elevator advantages

Low Installation Costs

Due to its advanced engineering, this device requires less space and preparation than traditional elevators, significantly reducing the overall project costs.

Space-Saving Design

The lift is designed to be installed even in extremely narrow spaces, making it an indispensable solution for buildings where floor area is limited.

Simple Replacement of Old Elevators

The MB400 is ideal for renovation projects, as it can be installed into existing shafts with only minimal structural adjustments.

Fast and Smooth Installation

Our efficient installation process ensures that your home life or business operations are minimally disrupted, with the lift ready for use in a very short time.

One-Touch Control

Unlike most platform lifts, the MB400 operates like a standard elevator—there is no need to hold the button during travel, providing the highest level of user comfort.

High Safety Standards

A wide range of integrated safety features and precision manufacturing guarantee a smooth and secure journey for every user.

Technical specifications

Drive system

Screw-driven

Nominal load

450 kg / 5 persons

Lifting speed

0.15 m/sec (9 m/min)

Lifting height

Up to 13 meters

Number of stops (floors)

Up to 6

Platform dimensions (length x width, mm)

1100 x 1400

* Other dimensions available

Shaft dimensions (length x width, mm)

1610 x 1700 (1 door)

1610 x 1850 (2 doors)

* Custom measurements available

Space requirements without prefab shaft (length x width, mm)

1560 x 1650 (1 door)

1560 x 1800 (2 doors)

* Custom measurements available

Pit (depth, mm)

100

Door dimensions (width x height, mm)

900 x 2000 (when 1100 x 1400 platform)

* custom measurements available

Door configuration

up to 2 doors per stop

Shaft walls

Steel panels or tempered glass panels

Steel panels or tempered glass panels

RAL 9006 (light grey aluminium)
* lift can be painted in any RAL colour

Soft start/stop

Standard equipment

Power supply

380-400 V 3 phases, 16A, 50 or 60 Hz

Motor

3.0 kW

Noise level

Less than 70 dB

Control system

Micro controller

Technical safety equipment

Protective edge around the platform, emergency stop buttons on the platform and in the shaft, emergency stop switches, electronic speed control, overload detectors, door opening and locking control, screw impact sensors, electronic motor performance control.

European standard compliance

EN 81-41:2010,

EN 81-20:2020,

EN 81-58:2018
